QIDI TECH ASA-Aero 3D Printer Filament
QIDI ASA-Aero is a type of lightweight 3D printing filament, specifically developed for the fields of aircraft models, ship models, drones, etc. ASA-Aero controls the foaming ratio of the material by adjusting the nozzle temperature during the printing process so that the density of the material extruded by the nozzle can be adjusted within a certain range. With this technique, it is easy to reduce the weight of the model. In the best-case scenario, the model weight can be reduced to 50% of a model printed with ordinary ASA. In addition to that, the matte texture of the printed surface can reduce the visibility of printed layers and thus give a smooth surface finish.
On-Demand foaming technology: QIDI ASA-Aero is a type of ASA filament that will start foaming with the aid of a blowing agent during the printing process. The blowing agent is in an unexcited state in the ASA filament before printing, During the printing process，by adjusting the printing temperature, the foaming ratio of the blowing agent can be easily controlled. The maximum foaming ratio can reach 250%.
Meanwhile, QIDI ASA-Aero retains the original UV aging resistance and high heat resistance of ASA material, which is suitable for long-term use in high-temperature outdoor environments.
On-Demand Foaming Technology
ASA-AERO:
The maximum foaming ratio of ASA-Aero flament can reach 250%.
Ordinary ASA:
Ordinary ASA filament has less foaming ratio.
Lightweight 3D Printing Filament
ASA-AERO:
Model weight can be reduced to 40% of a model printed with ordinary ASA.
Ordinary ASA:
Weight of ordinary ASA filament 55.8g.
100% Vacuum Packaging
It is not easy to absorb moisture and can be stored for a long time. And ensure that the filament is dry and flexible, not easy to break.
Compatible With Most of FDM 3D Printers
We highly recommend the use of ASA-Aero filaments in conjunction with the QIDI TECH X-Max 3 3D printer and QIDI TECH Filament Dryer.
Product Size
Spool
Inner Diameter: 5.7cm/2.24"
Outer Diameter: 19.9cm/7.84"
Height: 6.6cm/2.6"
Package
Length: 22cm/8.66"
Width: 21.5cm/8.47"
Height: 7.1cm/2.8"
Printing Tips
Recommended Printing Conditions:
Recommended Nozzle Diameter ≥0.4 mm
Print speed 30-90 mm/s
Recommended Build Surface Treatment PEI Film
Build Plate Temperature 80-110°C
Raft Separation Distance 0.18-0.2 mm
Cooling Fan Speed 0%-50%
1. Since ASA-Aero adops the ‘on-demand foaming’ technology, the filament will continue to expand in the nozzle after being heated during the printing process. Therefore, it will cause unavoidable stringing during the nozzle movement. Even adjusting the retraction setting in the slicing software cannot solve this problem. Based on the above, it is recommended to turn off the retraction setting.
2. Because ASA materials have a high glass transition temperature, a certain ambient temperature（40-70°C） is required during printing to release the internal stress of the printed parts and reduce warping. When printing thin-walled models without any form of insulation, it is recommended to use nozzles with a diameter of 0.6mm or more to ensure the strength of printed parts and reduce shrinkage.
3. When printing with ASA-Aero filaments, please place the enclosed printer in a ventilated environment.
For more details please refer to: Filament Guide on WIKI.
- What is ASA-Aero Filament? - ASA-Aero Filament is a special lightweight material used in 3D printing. It's perfect for making models like planes, ships, and drones. Its unique properties allow printed items to be much lighter than those made with regular materials, sometimes weighing only half as much!
- How is ASA-Aero different from other filaments? - ASA-Aero Filament stands out because it uses a special foaming technology that makes it lighter while still strong. This means you can have beautiful models that are easier to handle. Plus, the matte finish helps hide any lines or imperfections from printing.
- What are the best settings for printing with ASA-Aero? - To get the best results with ASA-Aero, use a nozzle that's 0.4 mm or bigger, and set your print speed between 30 to 90 mm/s. Keep the build plate temperature between 80 to 110°C for better adhesion and quality.
- Can ASA-Aero support outdoor use? - Yes, ASA-Aero is designed for outdoor use! It can resist both UV rays and high heat, making it great for items that will be exposed to the sun and weather for long periods.
- How do I prevent warping when using this filament? - To reduce the risk of warping, keep your printer's environment warm (between 40-70°C) during printing, especially if you're working with thin-walled models.
- Why should I use ASA-Aero for my 3D projects? - Using ASA-Aero helps you create lighter models without sacrificing strength. The special foaming technology means your model can be both aesthetically pleasing and functional, making it ideal for detailed designs.
- Is it safe to print with ASA-Aero? - While ASA-Aero is safe to use, it's important to print in a well-ventilated area as it can release fumes. If possible, use an enclosed printer to help manage airflow.
- How do I store ASA-Aero Filament? - Store ASA-Aero Filament in a dry place, away from direct sunlight. Keeping it in an airtight bag can help protect it from moisture and ensure it performs well when you use it again.
- Is ASA-Aero compatible with all printers? - ASA-Aero is compatible with most 3D printers that can handle ASA filaments, especially those with a heated bed and nozzle of 0.4 mm and above. Always check your printer's specifications!
- What should I do if I experience printing issues? - If you run into problems while printing with ASA-Aero, try adjusting the temperature settings or checking for clogs in the nozzle. Make sure your print surface is clean and suitable for this type of filament.
